Name: Landini Landforce 115 MFWD Open Station (Harrismith)
SKU: 505064
Price: 320000 ZAR
Availability: InStock

Worcester:

Click to call: +27 87 820 7101

Or send an e-mail: Leon.Tarr@afgri.co.za

Harare:

Click to call: +263 77251 4350

Or send an e-mail: graeme.smith@afgri.co.za

Grootvlei:

Click to call: +27 87 820 1077

Or send an e-mail:

PC Garage:
Click to call: +27 82 323 7998

Or send an e-mail:

Having the utility vehicles come pre-wired for a winch from the factory greatly reduces the winch install time. Two of the RSX860i chassis come from the factory pre-wired for a winch: all power steering models and the winch-ready chassis.

Components included in the winch-ready chassis factory installed:

Winch wiring harness
Negative winch battery cable
Winch disconnect wiring harness

Chassis with prewiring for winch

A dealer installed version of the WARN® ProVantage 3500-lb (1587.6-kg) winch for these chassis is available through Parts. Please reference the Price Pages/Configurator for the attachment number.

The following factory-installed packages are available as PR15 (priority replenishment) configurations, and are targeted to be available at your dealerships within 15 calendar days of order entry.

RSX860i Power Steering with WARN® winch and protection package (available in green and yellow, REALTREE® HARDWOODS HD® camo).

Shown in camo; also available in green and yellow. Shown with optional spot lights and half windshield.

Factory package includes:

Power steering
Yellow alloys on green and yellow vehicles, black alloys on camo vehicle
Sport seats
FOX® monotube shocks
2-in. (50.8-mm) front receiver with recovery loops
WARN® 3500 ProVantage winch
Pre-runner bumper
Rear bumper
Cargo box rails

RSX860i power steering winch ready with FOX 2.0 Performance Series piggyback shocks and protection package (available in green and yellow)

Shown with optional spot lights, half windshield, winch

Factory package includes:

Power steering
Winch ready
14-in. (355.6-mm) yellow alloys
Sport seats with sport steering wheel
FOX 2.0 Performance Series shocks with piggyback reservoir
Pre-runner bumper
Rear bumper
Cargo box rails

Build-to-order options available

The RSX860i can be configured the way the operator wants it. The build-to-order vehicles start with a choice of three different chassis:

Base chassis: no power steering, not winch ready. The vehicle can still be configured with the choice of colors, wheel/tires, seats, shocks and protection components.
Winch-ready chassis: no power steering, winch ready from the factory. Configurable with choice of colors, wheel/tires, seats, shocks, winch and protection components.
Power steering chassis: power steering, winch ready. Configurable with choice of colors, wheel/tires, seats, shocks, winch and protection components.

If orders are build to order, they will be sourced and a FDD assigned based on availability.

REALTREE HARDWOODS HD is a trademark of Jordan Outdoor Enterprises Limited. Warn is a trademark of Warn Industries, Inc. Fox Shocks is a trademark of Fox Factory Incorporated.

The cargo box consists of a high-density polyethylene copolymer composite material that eliminates rust, dents, and reduces noise. This large, one-piece design has rounded inside corners to ensure material removal when tilted. The composite box is highly ribbed and supported with a welded steel-ladder structure to ensure hard-driving performance and longevity. The three highly styled exterior pieces are made of thermoplastic polyolefin (TPO) for extra durability.

Cargo box tailgate

Tailgate handle

Removable tailgate

Tailgate pivot

Removable lanyards

The tailgate can be opened or removed for easier cleanout and to carry longer items. It features truck-like performance and can be operated with one hand.

The tailgate’s pivot point is made of hardened steel for durability and designed for tool-less removal. The standard lanyards can also be disconnected without tools to remove the tailgate for convenient loading and unloading tasks.

Cargo box tilt and removal

Integrated handle for manual cargo-box tilt

The cargo box ease of use is critical to performing tasks quickly and efficiently. Starting with the truck-style tailgate, the removal of content in this cargo box is much easier. The manual release functions as the lift lever as well, done in a smooth, one step motion. It can even be tilted from both sides of the vehicle. To reduce the overall effort of lift, the pivot point of the cargo box is closer to the center. The combination of easy-to-use attributes makes this cargo box best in class.

With the removal of two bolts, the cargo box can easily be detached from the vehicle frame for ease of servicing.

Integrated tie-down points

Integrated tie-down point in cargo box bed

Additional tie-down points

The cargo box offers integrated tie-down points for increased versatility. Tie-down points are located in the following areas:

Flip-up D-shaped rings in all four corners inside the cargo-box bed
Multiple points along the edge of the cargo box side walls
Tie-down bars on either side of the cargo box with optional cargo box rail kit. This kit also provides a mounting system using accessories that possess the 25.4-mm (1-in.) quick clamp.

Optional accessories

Cargo box rail system

Optional accessories for the cargo box include:

Factory-installed cargo box rail system
Cargo box bed mat
Cargo box wall extensions

Specifications

Length	32.3 in. (82 cm)
Width	47.6 in. (120.9 cm)
Depth	11.7 in. (29.6 cm)
Volume	8.9 cu ft (0.25 m³)
Weight capacity	400 lb (181.4 kg)
Dump angle Bed height (from ground)	45 degrees 30 in. (76.3 cm)

CAUTION: Carrying extra-long cargo that extends beyond the box can adversely affect stability.

The Gator™ RSX High-Performance Series Utility Vehicles are equipped with rack and pinion steering with optional power steering, and a dual A-arm front suspension. These automotive-type systems exhibit excellent handling characteristics, as well as responsive steering and low steering effort.

Automotive-type rack and pinion steering with optional power steering

RSX860i with optional power steering

Automotive-type rack and pinion steering features include:

Optional electronic power-steering assist system (EPAS). Features of EPAS include:
- Anti-kickback feature reduces the amount of steering unwinding when traversing difficult terrain.
- The system is speed sensing and adjusts steering effort as the speed of the vehicle changes.
  - As speed increases there is less steering assist for improved road feel.
  - As speed decreases steering assist increases to give lower steering efforts for improved maneuverability.
- A warning/functional light on the instrument panel provides self-diagnostics and a warning light in the situation of no assist.
- Torque sensor measures steering wheel input so the on-board computer can provide the appropriate output for various driving situations.
Steel ball-bearings secure the steering shaft and delivers smooth, responsive operation
Tight turn radius of 12.3 ft (3.7 m) for excellent maneuverability
Completely sealed rack-and-pinion for long life
Low steering ratio (lock-to-lock steering wheel rotations) provides more responsive steering and less operator input
Shaft U-joints are phased for a smooth, uninterrupted motion of the steering wheel
Ackerman steering design provides more responsive steering, decreases tire wear when used on hard surfaces and is turf friendly (see description below)
Minimal bump steer eliminates unintended vehicle direction changes when traversing terrain and permits less feedback to the steering wheel (see description below)

The tire scrubbing, which also creates unwanted heat and wear in the tire, can be eliminated by turning the inside wheel at a greater angle than the outside one (Ackerman steering).

NOTE: Some competitors use parallel steering instead of Ackerman steering.

Bump steering defines the change in the forward steering angle (thus wheel position) as the suspension travels through its full motion. A large amount of angular change (5 degrees to 7 degrees) will alter the vehicle’s direction and excessively move the steering wheel.

RSX front suspension detail

To complement the capable powertrain on the RSX860i, the RSX is equipped with four-wheel independent suspension. This unique suspension setup provides an unparalleled ride over challenging terrain and excellent handling through corners.

The engineering team in collaboration with engineering firms that consult with Formula 1®, NASCAR®, and INDYCAR® teams, built a sport-tuned suspension system for class-leading operator comfort, no matter what the terrain, and handling that makes one think they are on rails.

Dual A-arm front suspension features include:

Dual, wide-arch A-arm design provides maximum front-wheel control, precise steering, and maximum ground clearance out to the wheel
9 in. (23 cm) of travel provides ample compression and wheel extension, which keep all four wheels on the ground for superior traction and vehicle control
Exclusive aluminum-body, high-pressure monotube shocks or piggyback shocks; both provided by Fox Shocks™ racing shocks (see more details below)
Solid anti-roll bar, with fully rubber isolated connecting links and pivots, is tuned to provide the most agile and predictable handling
Camber during compression to compensate for body roll and to maintain an optimal tire contact patch for improved cornering grip
Increasing vehicle width during compression for additional stability.
High-strength ASTM 80-55-06 ductile cast-iron knuckle and upper A-arm to support the high stresses of the shocks, constant velocity (CV) shaft, and wheels
Automotive-style fully boxed and welded-steel lower A-arms to minimize unsprung mass and maximize strength
Maintenance-free rubber torsional A-arm pivots for long life and quiet operation
CV shaft protection from sticks that may puncture the rubber boot
Anti-dive front suspension geometry provides a solid platform for confident braking

RSX rear suspension detail

Multi-link independent rear suspension (IRS)

Multi-link IRS rear suspension features include:

Exclusive multi-link semi-trailing arm rear suspension moves wheel rearward and outward in compression
9 in. (23 cm) of travel provides ample compression and wheel extension, which keeps all four wheels on the ground for superior traction and vehicle control
Exclusive aluminum-body, high-pressure monotube shocks or piggyback shocks; both provided by Fox Shocks (see more details below)
Solid anti-roll bar, with fully rubber isolated connecting links and pivots, is tuned to provide the most agile and predictable handling
Camber during compression to compensate for body roll and to maintain an optimal tire contact patch for improved cornering grip
Increasing vehicle width during compression for additional stability.
High-strength ASTM 80-55-06 ductile cast-iron knuckle and lower A-arm to support the high stresses of the shocks, CV shaft, and wheels with the toughness to survive impacts from boulders
Heat-treated aluminum cast upper A-arms to minimize unsprung mass
Maintenance-free rubber torsional A-arm pivots for long life and quiet operation

Standard Fox Shocks

Standard equipment shocks on the base model– front and rear suspension

Exclusive aluminum-body, high-pressure monotube Fox racing shocks
- Fully adjustable spring preload for different driving styles
- High-pressure nitrogen gas is separated from the damping oil by an internal floating piston (IFP). The separation prevents aeration (frothing) and viscosity degradation of the oil which improves damping consistency and performance fade.
- Pressure and heat generation in the monotube is less than a traditional twin-tube shock, allowing for better vehicle control in aggressive conditions.
- The single aluminum shell of the monotube design allows for more efficient heat rejection and lower overall unsprung mass.
- Mounting the shaft end of the shock to the suspension arm lowers the unsprung mass of the suspension system, leading to improved suspension response.

Upgrade Fox 2.0 Performance Series shocks

Reservoir with compression adjustment

Upgrade Fox 2.0 Performance Series shocks

Upgrade shocks—Front and rear suspension

RSX tuned Fox 2.0 Performance Series shocks
- Fully adjustable spring preload for different driving styles and ride height settings
- Piggyback reservoir houses high-pressure nitrogen gas, separated from the damping oil by an internal floating piston (IFP). The separation prevents aeration (frothing) and viscosity degradation of the oil which improves damping consistency and performance fade.
- Large, 2.0 aluminum bodies help reduce internal pressures and improve heat dissipation, which results in consistent fade-free performance in aggressive riding conditions.
- Compression adjustment allows the user to tune damping rates for different riding preferences and trail conditions
- Tuned with Fox factory support on some of the most grueling trails in the United States

Fox Shocks is a trademark of Fox Factory Incorporated. NASCAR is a trademark of NASCAR. INDYCAR is a trademark of Brickyard Trademarks Incorporated. Formula 1 is a trademark of Formula One Licensing BV, a Formula One Group Company.
